Pallas Home UV System – Pre-Filtration UV Water Purifier
£410.00
As the demand for sustainable water solutions continues to grow, rainwater harvesting has emerged as an effective and eco-friendly way to supplement residential water needs. However, untreated rainwater may contain impurities such as dirt, debris, and micro-organisms that can compromise its safety for household use. To ensure the quality and safety of rainwater and well water, proper treatment systems are essential. The Pallas Home UV is an integrated water purification system that effectively eliminates harmful impurities & microorganisms, providing clean and safe water for your home and family.
Features
- Delivers Pure, Safe & Clean water - The Pallas Home UV system provides water that’s pure, safe, and clean, giving your family peace of mind with every drop
- High Filtration Water flow - The Pallas Home UV system maintains high water pressure while filtering out contaminants, ensuring an uninterrupted supply of purified water.
- High output UV lamp Equipped with a high-output UV lamp, the compact Pallas Home UV ensures maximum effectiveness in eliminating harmful microorganisms.
- Uses ultraviolet rays to kill micro-organisms present in the water. The Pallas Home UV system harnesses the power of ultraviolet rays to neutralize bacteria, viruses, and other harmful microorganisms in your water. UV disinfection is a natural non-chemical method of water treatment.
General Conditions for Installation
The Pallas Home UV all-in-one water purification system delivers water treatment in three stages - filtration, adsorption and UV disinfection - to remove sediment, bacteria and other pathogens while improving taste, clarity and odour.
1ST STAGE FILTRATION
The sediment filter cartridge removes common impurities such as sand, silt, dirt & rust particles from the water.
2ND STAGE FILTRATION
The carbon block filter cartridge adsorbs the chlorine, organic matter, odour, smell turbidity and suspending particles.
3RD STAGE UV WATER PURIFIER
The ultraviolet rays kill the present micro-organisms. This is a chemical-free process that destroys bacteria and other harmful pathogens in the water. No pathogen is known to be immune to UV Disinfection.
- MODEL – PHUV33
Operating max pressure – 7 bar
Ambient air temperature – 2-50°C
Maximum humidity – 95%
Maximum iron – 0.3 ppm
Minimum UVT – 75% - DIMENSIONS
Width – 600 mm
Height – 425 mm
Depth – 200 mm - FLOW RATES
- Maximum rated flow at dose of 16 mJ/cm2 – 57LPM
- Maximum rated flow at dose of 30 mJ/cm2 – 30LPM
- Maximum rated flow at dose of 40 mJ/cm2 – 23LPM
- ELECTRICAL
Voltage – 100-240V AC
Frequency – 50/60Hz
Max. power consumption – 43W
Lamp power – 33W - OTHER
UV Champer Material – SUS 304
Inlet/Outlet -1″ inch
Rated service life of lamp – 9000 hours - UV System Certification – CE
UV System Certification
CE
