Ecosoft EXLP8040 Membrane Element

Specifications

Membrane type — spiral-wound element with polyamide thin-film composite

• Active area — 37.2 m²
• Operating pressure — 6.9 bar
• Flow rate — 48.4 m³/day
• Stabilized salt rejection — 99.2 %

* Permeate flow and salt (NaCl) rejection based on the following standard test conditions: 500 mg/L NaCl, 25 °C, permeate recovery asspecified below. Permeate flow rate for one element does not exceed ±20% of the nominal value.

Operating parameters

• Maximum operating water temperature — 45 °C
• Maximum operating pressure — 41 bar
• Maximum element pressure drop — 1.0 bar
• pH range, continuous operation — 3...10
• pH range, short-term cleaning — 2...12
• Maximum Feed Silt Density Index (SDI) — 5
• Free chlorine tolerance < 0.1 mg/L
