Clack Carbon Filter for Chlorine, Colour and Organic removal

Clack Carbon Filter for Chlorine, Colour and Organic removal - Image 2

Clack Carbon Filter for Chlorine, Colour and Organic removal

Price range: £450.00 through £12,375.00

Granular Activated Carbon (GAC) filters are an excellent choice for removal of chlorine, taste, odour, or organics (bone charcoal will also reduce some heavy metals). Coconut, coal, bone or wood based are available. Flow is based on dechlorination and is about a 3 minute contact time. For colour/organics this time needs to be at least 10 minutes so the max flow rate is reduced.

General Conditions for Installation

Connection IN & OUT: Equal to valve size
Option side mount: N/A
Drain connection(*): 3/4", 1", 1.25", 1.5", 2" or 3" depending on flow required
Electrical rating: 230V 50Hz 12V Transformer, 24V
Max power rating: 6W
IP protection class: Double isolated transformer
Minimum inlet pressure : 200 kPa (2 bar)
Maximum inlet pressure: 600 kPa (6 bar)
Vacuum: no allowance
Average pressure loss (**): 100 kPa (1 bar)
Min-max water temperature: 4-43°C

Carbon Filter Options

Clear

- +

SKU N/A Categories Clack Water Filters, Water Filters

Product Manuals
Specifications

Clack WS1 & WS1.25 Service Manual

Clack WS1.5 & WS2 Service Manual

Clack Carbon Filters Data Sheet

Valve/ Vessel size/ Media Volume Kg/ Max Dechlorination Flow/ Backwash

Clack WS1TC 10×54 20 0.8³/hr 0.7³/hr
Clack WS1Cl 10×54 20 0.8³/hr 0.7³/hr
Clack WS1Cl 12×52 25 1.4³/hr 0.9³/hr
Clack WS1Cl 13×54 35 2.1³/hr 1.1³/hr
Clack WS1Cl 14×65 50 2.4³/hr 1.3³/hr
Clack WS1Cl 16×65 63 3.2³/hr 1.7³/hr
Clack WS1.25Cl 18×65 85 4.0³/hr 2.2³/hr
Clack WS1Cl 18×65 85 4.0³/hr 2.2³/hr
Clack WS1.5Cl 21×60 100 5.4³/hr 3.0³/hr
Clack WS1Cl 21×60 100 5.4³/hr 3.0³/hr
Clack WS1.5Cl 24×69 150 6.5³/hr 3.8³/hr
Clack WS1.5Cl 24×69 150 6.5³/hr 3.8³/hr
Clack WS2Cl 30×72 200 8.9³/hr 6³/hr
Clack WS2Cl 36×72 300 14³/hr 8.5³/hr
Clack WS2Cl 42×78 450 18³/hr 12³/hr
Clack WS2QC 48×82 550 22³/hr 18³/hr
Clack WS3 Top 63×86 950 38³/hr 30³/hr
