Autotrol Magnum 298 IT Industrial Valves

• Service flow rate: 17.3 m³/hr
• Backwash flow rate: 20.2 m³/hr
• Operating pressure: 1.8 to 6.9 bar
• Water temperature: 2°C to 38°C
• Type of valve:
  • 293: Filter
  • 298: Softener
• Tank thread 4 inch
• In/out 2 inch
• Brine line ¾ inch
• Riser tube diameter 1.5 inch

Operating Pressure 1.5 to 8 bar for the 742

742 Time Lock

• simple, economic electronic time clock (chronometric)
• 7- or 99- day regeneration settings
• Filter or conditioner setting in one control
• Fully programmable cycle times
• Salt setting
• Single controller operates Autotrol 255, 263, 268, 278 models, and Pentair Water Magnum and Magnum IT with one controller

762 Demand

• Simple, economic electronic demand (volumetric)
• Calendar override – 99
• 28- day variable reserve
• Filter or conditioner setting in one controller
• Automatic capacity calculations
• Fully programmable cycle times
• Salt setting in 1-pound increments (bs/cu ft)
• Operates 255, 263, 268, 278 and Magnum IT with one controller

All valves come with a no water bypass during generation cartridge as standard.
